System Power Rating |
: |
625 Watts (525 + 100) |
|
Frequency Range (-10 dB) |
: |
39 Hz -20 kHz |
|
Dimensions (H x W x D) |
: |
673 mm x 406 mm x 368 mm (26.5" x 16" x 14.5") |
|
System Type |
: |
Self powered 15", two-way, bass-reflex |
|
Maximum SPL Output |
: |
132 dB |
|
Frequency Response (±3 dB) |
: |
42 Hz - 18 kHz |
|
Input Connectors |
: |
2 x 1/4" TRS phone jacks balanced/unbalanced 1 x XLR / 1/4" TRS combo jack with XLR loop through |
|
Input Impedance |
: |
14k ohms |
|
Signal Indicators |
: |
Limit: Red LED indicates limiter active condition
Signal: Green LED indicates signal present
Mic: Indicates the MIC/LINE switch is in the "MIC" position
EQ: Individual Bass and Treble controls, center detent, 6 dB cut and boost
Bass +/- 6 dB (200 Hz turnover frequency)
Treble +/- 6 dB (4 kHz turnover frequency) |
|
Mic Input Gain |
: |
-Infinity to +40 dBu |
|
Line Input Gain |
: |
-Infinity to +4 dBu (+18 dBu maximum input level) |
|
|
Amplifier Design |
: |
Crown® Class-D |
|
LF Driver |
: |
1 x JBL 265F-1 380 mm (15") Differential Drive® integrated woofer with dual 2" voice coils |
|
HF Driver |
: |
1 x JBL 2414H 37.5 mm (1.5") annular polymer diaphragm, neodymium compression driver |
|
Coverage Pattern |
: |
100º H x 60º V nominal |
|
Crossover Frequency |
: |
1.7 kHz |
|
Material |
: |
Polypropylene, multi-purpose main & monitor |
|
Suspension / Mounting |
: |
36 mm pole socket with stabilizing screw, 5 x M10 suspension points |
|
Handles |
: |
One left/right side, one on top, with rubber grip |
|
|
Grille |
: |
Powder coated perforated steel with acoustically transparent cloth backing |
|
Net Weight |
: |
14.8 kg (32.5 lb) |
|
